GSS product characteristics
Capacity and storage
Energy storage capacity: 558 kWh
Electrical capacity: 280 Ah
Performance:
EMC Class: Class A
Noise: <75 dB
Operating temperature: -25°C to 50°C (-25°F to 122°F)
Maximum standby power consumption: 600 W
Level of protection: IP54 (Machine), IP67 (Battery)
Interface and operating system
Touch screen: 10 inch, capacitive, with Android operating system
Advertising display: 32 inches
Connectivity: 4G/WIFI/LAN, GPS, OCPP 1.6J
Payment system: Support contactless payment (NFC/Apple Pay), credit card POS, QR payment
Vehicle charging system
Total load power: 320 kW
DC charging voltage range: 200-1000 V
Charging protocol: ISO15118/DIN70121
Charging gun configuration: 250 A × 2 (CCS2 × 2)
Charging power with single hose: 200 kW
Thermal management
Battery cooling: Liquid
Battery heating: Liquid
Charging gun cooling: Natural
Power module cooling: Air
Safety and security
Anti-theft lock and access control system
Crash shutdown and fire protection
Indicator lights: Green/Red
Main product features
GSS POWER VS Typical Fast Charger
GSS power
Connects to the existing network infrastructure without civil works,
Achieve virtual scaling by the unit itself.
LWH small, relocatable
Easy installation
Flexible and highly efficient
Approval restriction
Space restriction
Installation
Network utilization status
Typical fast charger
Need for approval for Groud’s electrical and network infrastructure upgrade
Fixed location
More investment, greater difficulty
Underperformance
